General  Specification 12ND100 15ND100
Norminal Diameter :    12 inch 15inch
Power Rating :        500 W 600W
Norminal Impedance :  8Ohm 8Ohm
Sensitivity :      95dB 96dB
Frequency Range :    45HZ-3.5KHZ 40HZ-2.5KHZ
Chassis Type: Aluminium Aluminium
Magnet Type:    Neodymium Neodymium
Magnet Weight :     90x10mm 90x10mm
Voice Coil ;    4"/99.2mm 4"/99.2mm
Coil Material    SV Inside-out SV Inside-out
Former Material :    Glass Fiber Glass Fiber
Voicecoil Winding Width:    18mm 18mm
Cone/Surround Material :     Paper/Cloth Paper/Cloth
Suspension :   Double Spider Double Spider
X-mas:     8mm 8mm
N/G  Weight  4.5/5.5kg 5/6.5kg
Dimension WxDxH 37x37x22cm 44x44x25cm
Thiele & Small Parameters
Re  5.3ohm 5.3 ohm
Fs 45HZ 50hz
Mms 133g 148g
Mmd 126g 150g
Qms 9.77 6.67
Qes 0.33 0.5
Qts 0.32 0.46
Vas 40.08 65.8
BL 24.9 22.8
SD 56.4 87.6
Features
  1000 Watts  Max Power Handling 1200 Watts  Max Power Handling
  Neodymium Magnet Neodymium Magnet
  Double Spider Suspension Double Spider Suspension
  Die Cast Aluminium Chassis Die Cast Aluminium Chassis
