Model :
|
SRX812ADSP
|
SRX815ADSP
|
|
Type
|
2 way ,full arrange active
|
2 way ,full arrange active
|
|
Cabinet:
|
MDF, Plywood
|
MDF, Plywood
|
|
LF driver
|
1x 12 inch, 2.5"VC,
|
1x 15 inch, 3"VC,
|
|
60 Oz magnet,
|
80 Oz magnet,
|
|
HF driver
|
1.75"VC /44.4mmTitanium
|
1.75"VC /44.4mmTitanium
|
|
Sensitivity
|
125dB
|
127dB
|
|
Amplifier:
|
Class d,DSP,BI-AMP
|
Class d,DSP,BI-AMP
|
|
Frequency :
|
50-20Khz
|
45-20Khz
|
|
RMS Power
|
400 W
|
500 W
|
|
Max Power
|
800 W
|
1000 W
|
|
Impedance
|
8 Ohm
|
8 Ohm
|
|
Crossover
|
2.5Khz
|
2.2Khz
|
|
Outer carton:
|
48.5*47*69.5CM
|
53.5*51.5*75CM
|
|
|
|
|
|
Model:
|
SRX818ADSP
|
SRX828ADSP
|
|
Type
|
Active system
|
Active system
|
|
Cabinet:
|
MDF, Plywood
|
MDF, Plywood
|
|
LF driver
|
1x 18"subwoofer, 3"VC,
|
2x 18"subwoofer, 3"VC,
|
|
80 Oz magnet,
|
80 Oz magnet,
|
|
HF driver
|
N/M
|
N/M
|
|
Sensitivity
|
130dB
|
133dB
|
|
Amplifier:
|
Class d,DSP,BI-AMP
|
Class d,DSP,BI-AMP
|
|
Frequency :
|
35-150Khz
|
35-150Khz
|
|
RMS Power
|
1000 W
|
1200 W
|
|
Max Power
|
2000 W
|
2400 W
|
|
Impedance
|
8 Ohm
|
8 Ohm
|
|
Crossover
|
150hz
|
150hz
|
|
Outer carton:
|
73.5*74*64CM
|
73.5*125.5*64CM
|
|
|
|
|
|
Model:
|
SRX825ADSP
|
|
|
Type
|
Active system
|
|
|
Cabinet:
|
MDF, Plywood
|
|
LF driver
|
2x 15 inch, 3"VC,
|
|
80 Oz magnet,
|
|
HF driver
|
1.75"VC /44.4mmTitanium
|
|
Sensitivity
|
130dB
|
|
Amplifier:
|
Class d,DSP,BI-AMP
|
|
Frequency :
|
45-20Khz
|
|
RMS Power
|
700 W
|
|
Max Power
|
1500 W
|
|
Impedance
|
8 Ohm
|
|
Crossover
|
2Khz
|
|
Outer carton:
|
54*55.5*114.5CM
|
|
