PE

Model	PE10F	PE12F	PE15F
Type	2 way , full arrange passive systerm	2 way , full arrange passive systerm	2 way , full arrange passive systerm
Cabinet	MDF ,Painted finish	MDF ,Painted finish	MDF ,Painted finish
LF driver	1x 10 inch, 2"VC, 40 Oz magnet	1x 12inch, 2.5"VC, 50 Oz magnet	1x 15 inch, 3"VC, 60 Oz magnet
HF driver	1.35 VC Titanium	1.35 VC Titanium	1.75"VC Titanium
Sensitivity	95dB	96dB	98dB
Frequency response	55-20Khz	50-20Khz	45-20Khz
RMS Power	200 W	250 W	350 W
Max Power	400 W	500 W	700 W
Impedance	8 Ohm	8 Ohm	8 Ohm
Crossover	2.5Khz	2.5Khz	2.5Khz

Model	PE215F	PE18SUB	PE218SUB
Type	3 way , full arrange passive systerm	passive subwoofer	passive subwoofer
Cabinet	MDF ,Painted finish	MDF ,Painted finish	MDF ,Painted finish
LF driver	2x 15 inch, 3"VC, 60 Oz magnet	1x 18 inch, 4"VC, 125 Oz magnet	2x 18 inch, 4"VC, 125 Oz magnet
HF driver	1.75"VC Titanium	None	None
Sensitivity	101dB	98dB	103dB
Frequency response	40-20Khz	35-300hz	30-300hz
RMS Power	600W	500W	900W
Max Power	1200W	1000W	1800W
Impedance	8 Ohm	8 Ohm	8 Ohm
Crossover	1.8Khz	150Hz	150Hz
