Model |
PD12F |
PD15F |
PD215F |
|
Type |
2 way ,
full arrange passive systerm |
2 way ,
full arrange passive systerm |
3 way ,
full arrange passive systerm |
|
Cabinet |
MDF ,Painted finish |
MDF ,Painted finish |
MDF ,Painted finish |
|
LF driver |
1x 12inch, 2.5"VC,
50 Oz magnet,steel basket |
1x 15 inch, 3"VC,
60 Oz magnet,steel basket |
2x 15 inch, 3"VC,
60 Oz magnet,steel basket |
|
HF driver |
1.35 VC Titanium |
1.75"VC Titanium |
1.75"VC Titanium |
|
Sensitivity |
96dB |
98dB |
101dB |
Frequency
response |
50-20Khz |
45-20Khz |
40-20Khz |
|
RMS Power |
250 W |
350 W |
600W |
|
Max Power |
500 W |
700 W |
1200W |
|
Impedance |
8 Ohm |
8 Ohm |
8 Ohm |
|
Crossover |
2.5Khz |
2.5Khz |
1.8Khz |
|
Model |
PD18SUB |
PD218SUB |
|
Type |
passive subwoofer |
passive subwoofer |
|
Cabinet |
MDF ,Painted finish |
MDF ,Painted finish |
|
LF driver |
1x 18 inch, 4"VC,
125 Oz magnet,cast aluminium basket |
2x 18 inch, 4"VC,
125 Oz magnet,cast aluminium basket |
|
HF driver |
None |
None |
|
Sensitivity |
98dB |
103dB |
|
Frequency response |
35-300hz |
30-300hz |
|
RMS Power |
500W |
800W |
|
Max Power |
1000W |
1600W |
|
Impedance |
8 Ohm |
8 Ohm |
|
Crossover |
150Hz |
120Hz |
|
